Hosipital High Frequency Mobile Digital Radiography System

  • DR200
  • Poweam

Usage:



This unit is high frequency combined digital X-ray radiography medical diagnostic equipment, it is used in radiography department, orthopedics, wards, emergency room, operation room, ICU, etc. It can satisfy the requirement of parts of body such as head, limbs, chest, spine, lunmer, stomach.



Basic configuration:



1.  high frequency and voltage generator



2. Color graphical touch LCD control system



3. Panel detector with free movement



4. High quality IPC



5. Large size medical LCD display



6. New type mobile column rack



7. Symmetric adjustable,wireless ranging rotatable collimator with lamp



8. Electric assistance drive system



9. Cable exposure hand brake



10. Wireless remote control exposure device




X-ray generator:



1. 25KW compact x-ray generator;



2. High frequency of 60Khz;



3. With high technology to reduce the radiation;


Unique Power supply way:



1. Supers capacitor to supply power in photography and durable life;



2. Li-Battery to supply power in mechanical movement;


Mechanical movement:



1. The horizon arm can be contracted freely;



2. The pillar has the electronic up and down movement; and be rotated 360 degree;



3. X-ray tube is rotary and moves left and right with 90 degree;



4. Collimator can be rotated left and right with 90 degree;



5. Comprehensive integration control drive


Software:



LCD touch screen operation panel to control the machine conveniently;


Technical parameters



Type

Item

Spec


Max output power

25kW


Main Inverter Frequency

60kHz


X-ray tube

Focus

Small focus:0.6; Large focus:1.3

Hige frequency X-ray

Rotation anode speed

3000rpm


Heat capacity

900kJ (1200kHU)


Tube current

200mA






Tube voltage

40-125kV






MAS

0.4-360mAs



Detector

Amorphous silicon detector







scintillator

cesium iodide



View

14″×17″


Digital detecotr

Pixel

2816×2304


Max spatial resolution

3.3Lp/mm







Pixel size

154μm







Output gray-scale

16bits

Digital image system





DQE

60%



Acquisition module

Gigabit nets collection








Built-in CONTEXTVISION



Image processing modle

GOPVIEW XR2 Enhance


Workstation


module, parameeters choosen



according to particular part






Image information

Dicom Storage



Dicom Print



management



Dicom transmission





Distance from floor to focus

Max:193cm; Min:73cm






Distance from focus to pillar

Max:122cm; Min:72cm





Physical construction

X-ray Tube components can rotate

±90º

performance

around the telescopic boom axis



Collimator rotate around vertical axis

±90°






Rotation range of pillar

0°~360°





Power supply



220V±10%   50/60Hz
